GeoServer GetLegendGraphic Fails With “Width (0) and height (0) cannot be <= 0″

I had a weird issue with WMS GetLegendGraphic requests failing with the following message:

<?xml version="1.0" encoding="UTF-8" standalone="no"?><!DOCTYPE ServiceExceptionReport SYSTEM "http://michael.mapfeeder.net:80/geoserver/schemas/wms/1.1.1/WMS_exception_1_1_1.dtd"&gt ;<ServiceExceptionReport version="1.1.1" &gt ;<ServiceException>
java.lang.IllegalArgumentException: Width (0) and height (0) cannot be <= 0
Width (0) and height (0) cannot be &amp;= 0
</ServiceException></ServiceExceptionReport>

This was weird because my request definitely included non-zero height and widths, like so:

/geoserver/wms?LAYER=parcel_area&REQUEST=GetLegendGraphic&FORMAT=image%2Fpng&STYLE=michael_test&WIDTH=20&HEIGHT=20

Eventually I tracked it down to an issue with the SLD xml. The XML was valid, but GeoServer didn’t like the use of CDATA tags inside of <Name>,<Title> and <ogc:Literal> tags.

So anywhere with formatting like this

<NamedLayer>
<Name>
<![CDATA[Parcel Area]]>
</Name>
<UserStyle>
<FeatureTypeStyle>
<Rule>
<Name>
<![CDATA[ Low Density Residential ]]>
</Name>
...

had to be changed to

<NamedLayer>
<Name>Parcel Area</Name>
<UserStyle>
<FeatureTypeStyle>
<Rule>
<Name>Low Density Residential</Name>
...

Once I got rid of the CDATA tags everything worked beautifully.

This issue was on GeoServer 2.5. YMMV, etc.

Posted in Computers, GIS Portfolio, Programming | Tagged , , , , | Leave a comment

Running ArcPy Scripts on a Linux Cluster or Super Computer

Sometimes you need more processing power from ArcPy than your ArcMap or ArcServer install can give you. In such cases your friendly campus super-computer may be helpful.

Your super-computing administrators can help you with the usual scripting, job allocation and other issues that come up with super computer jobs, but they may not be as familiar with the quirks of getting ArcPy on Linux working on the compute nodes of their super-computer.

Use Case

We used a 1 TB raster mosaic DEM of the state of Minnesota as input and ran the Solar Radiation Analysis tool on the whole state. It required more computing power than we could get on the servers we had available and so we processed some of it on the UMN Super Computer, Itasca.

What You’ll Need

  • ArcPy for Linux along with appropriate licenses
  • A network drive shared with all compute nodes on your cluster

We installed ArcPy for Linux by installing ArcGIS Server for Linux. ArcGIS Engine is also available for Linux and comes with ArcPy. These instructions will be for Arc Server, but I suspect that ArcGIS Engine are likely similar.

Background

ArcPy on Linux actually runs inside of [Wine](http://www.winehq.org/). Wine allows Windows applications to run on Linux. When you run ArcGIS Server for Linux’s install of Python you are actually running the same Windows version of python that you would be in ArcMap or ArcGIS Server for Windows.

We need to make a few modifications so that it will work in a clustered environment.

The main problem is that Wine expects that each user will have their own .wine directory. Wine implements the Windows registry. If you have multiple users (or nodes in the cluster) using the same .wine directory the registry will get corrupted when multiple users try to write at the same time.

Installation Instructions

Allow DOTWINE Override

Install ArcServer to a directory which is available to the compute nodes. Make sure that the directory is available through the same file path on the node you’re working on and the compute nodes.

Edit the arcenv file located in arcgis/server/framework/etc/arcenv. We need to make it possible to override the DOTWINE variable which points at the user’s windows applications (including the Windows version of Python and the Python libraries).

Replace the line that says:

DOTWINE=”$ARCGISHOME/framework/runtime/.wine”

with

if [ "x$DOTWINE"="x"];then
DOTWINE=”$ARCGISHOME/framework/runtime/.wine”
fi

Add Xvfb Support

ArcPy on Linux requires Xvfb. The call to Xvfb is made in init_Xvfb.sh. ArcGIS Server installs Xvfb libraries for RHEL and SuSE, and looks for the Ubuntu Xvfb libraries. The cluster we used ran Debian but was detected as Ubuntu.

We symlinked the RHEL Xfvb libraries to a directory named Ubuntu and everything worked fine.

cd server/arcgis/server/framework/runtime/xvfb
ln -s RHEL/ Ubuntu

In our case the compute nodes were missing libXdmcp.so which Xfvb needs, but the login node had them. Copy them from the login node to the compute nodes:

cd server
mkdir -p arc/libs
cp -L /usr/lib64/libXdmcp.so* arc/libs

Scripting Setup

With Xvfb set up and the ability to override the default .wine directory, it’s time to create a setup script. This script is what will be submitted to the server. It will set up environment variables and then launch the python script you actually want to run.

We start by setting up some variables and then make a fake ArcGIS server install. The fake install is a bunch of symlinks back to the real install — for most files and directories. The .wine directory however is actually copied so that we’re working off of our own copy.

The symlinks are needed because inside the .wine directory are relative symlinks which point to the ArcGIS Server files. You can’t just move the .wine directory and expect it to work.


#!/bin/bash


# Make a symlink clone of a directory
# If the destination directory exists, but is a symlink, the symlink
# will be removed and replaced with an actual directory
# actual directories will not be replaced
function fakedirs {
    sourcedr=$1
    destdir=$2

    echo "Making fake $destdir from  $sourcedr"

    # Make the dest dir if it doesn't exist
    if [[ -h $destdir ]];then
        rm -f $destdir
    fi
    mkdir -p $destdir

    # Switch to the dest dir
    pushd $destdir >/dev/null

    # For every file in the sourcedir, symlink to it in the dest dir
    for i in $sourcedr/*;do
        if [[ ! -e $(basename $i) ]];then
            ln -s $i
        fi
    done

    # Change back to the directory we were in
    popd >/dev/null
}


# Define the path to the ArcGIS Server install
REALARCINSTALL="/home/username/shared/arc/server/arcgis/server"

# Add the ArcGIS Server tools to your path
export PATH=$REALARCINSTALL/tools/:$PATH

# Add the arc/libs directory to your LD_LIBRARY_PATH so that libXdmcp.so* get picked up
export LD_LIBRARY_PATH=$REALDATADIR/arc/libs:$LD_LIBRARY_PATH

# Optionally set your wine debug level
export WINEDEBUG="-all"

# Define which directory you want to use for your wine install
# Note: This doesn't have to exist yet.
# Note: This should be distinct for each job on the cluster. It
# could be on the processing node's local hard drive, or it could be
# on a network share, but it needs to be one .wine directory per job.
# In a PBS environment the variable $PBS_VNODENUM will ensure that
# each job on the node gets its own number

FAKEWINETOP="/tmp/username/fakeWine_$(hostname)_$PBS_VNODENUM"

echo "Cloning Wine"
fakedirs $REALARCINSTALL $FAKEWINETOP
fakedirs $REALARCINSTALL/bin $FAKEWINETOP/bin
fakedirs $REALARCINSTALL/framework $FAKEWINETOP/framework
fakedirs $REALARCINSTALL/framework/runtime $FAKEWINETOP/framework/runtime

# Copy the actual wine directory now
# If there's already an actual .wine directory remove it and replace it
echo "Copying actual .wine dir #1"
if [[ -h $FAKEWINETOP/framework/runtime/.wine ]];then rm .wine;fi
rsync -rl $REALARCINSTALL/framework/runtime/.wine/ $FAKEWINETOP/framework/runtime/.wine/

echo "Copying actual .wine dir #2"
# If there's already an actual .wine directory remove it and replace it
if [[ -h $FAKEWINETOP/bin/.wine ]];then rm .wine; fi
rsync -rl $REALARCINSTALL/bin/.wine/ $FAKEWINETOP/bin/.wine/


#######################################################################################
#
# Copy any data you need locally for this job instance here
#

#######################################################################################
#
# Finally, we launch the actual job. Since Wine is still a little
# crashy, we're going to try to start the job up to 100 times
#

# After crashing we sleep for a random time, up to 19 seconds. If
# we're running multiple jobs on the same physical node we can have multiple
# jobs trying to start Xvfb at the same time which seems to cause
# intermittent race conditions. The random sleep time worked around this.

MAXTRIES=100
echo "Launching script on $(hostname)"
while [[ $MAXTRIES -gt 0 ]]; do
    $REALARCINSTALL/tools/python /home/user/path/to/your_code/myScript.py 2>&1
    echo "$(hostname) - wine down again ($MAXTRIES tries left) -"
    sleep $(( ( RANDOM % 10 )  + 10 ))
    ((MAXTRIES--))
done

echo "$(hostname) I tried to start python/wine 100 times. I'm giving up and going home."

Other Considerations

Besides getting Wine/Python working there were several other issues we came across.

Data transfer

Our input data was a one terabyte raster mosaic. For small jobs (20-40 nodes) the nodes were able to access the raster mosaic concurrently over a network drive. Beyond this scale delays were noticable. Since we were only reading from the raster mosaic I suspect that the issue was the network share, and trying to access the same set of files from that share from 200+ clients.

To work around this issue, we used the same symlinking trick we did for the ArcGIS server install to duplicate the structure of the file geodatabase which held the raster mosaic. The referenced rasters were symlinked to a path which corresponded to the location that the GeoDatabase expected to find them. The specific tiles needed for the computations were copied to the local compute node.

Incremental writes

In our case our output files were 500-700 MB each. The Solar Radiation Analysis tool writes these output files incrementally. Unfortunately, the network file system we were on did not deal well with multiple (100s or 1000s) of concurrent incremental large file writes.

For large jobs we experienced lots of data corruption. We found that the best solution was to write the resulting file to the local compute node’s disk and then copy the file all at once. Using this method avoided the pattern of corruption we were experiencing.

Posted in Computers, GIS Portfolio | Tagged , , , , , , , , | Leave a comment
